Count fixtures from PDF plans in hours.
Upload a plan set with a readable legend. Cuadrabot maps each supported code to the drawing, counts every placement, and returns an annotated PDF plus an Excel workbook—fully self-serve.
Source coordinates retained for every supported placement
Legend-code summary
168 source-linked placements
In hours
Automated self-serve delivery
Legend-linked
Codes, symbols, and visible plan locations
PDF + XLSX
Evidence and quantities you can keep
How it works
A clear chain from legend to placement.
The self-serve workflow verifies, maps, counts, validates, and delivers automatically. Legend samples and repeated reference views are excluded from installed-item totals.
Upload plans with a legend
Choose one or more legend-based scopes and upload a private PDF plan set.
Approve a fixed quote
We verify the actual PDF and page count on the server before quoting credits.
Cuadrabot maps and counts
The workflow reads the legend, maps supported codes and symbols, and records each source-linked placement.
Download the results
Validated marked PDF and Excel deliverables are released automatically when processing finishes.
Legend-based scope
Built for fixtures, devices, and defensible routed quantities.
A readable legend defines the catalog. For cable or conduit runs, a visible route and stated scale are required. Anything ambiguous is reported as a limitation instead of being guessed.
Electrical & lighting fixtures
Legend-coded luminaires, devices, equipment, and source-linked placements by code and location.
Explore this category02Cable & conduit runs
Supported visible routes measured only when the legend is readable and the drawing states a usable scale.
Explore this category03Other legend-coded devices
Repeatable counts for supported installed symbols, with ambiguous or unresolved codes flagged rather than guessed.
Explore this categoryWhat you receive
Legend-coded quantities with evidence you can check.
The useful product is not a mystery total. It is a reviewable package that lets an estimator trace each counted placement to its code and plan location.
Marked plan PDF
Every supported placement is tied to its page, legend code, and visible location.
Excel quantity workbook
Filterable rows and reconciled summaries by code, area, page, and floor.
Source evidence
Stable unit ID, sheet, area, method, confidence, and visible geometry.
Methodology and limitations
Clear scope boundaries, exclusions, ambiguous codes, and automated checks.
Simple service pricing
Know the scope before credits move.
The uploaded PDF—not a browser field—sets the verified page count. You see the fixed credit quote before confirming.
First verified takeoff
$49
One legend-based scope and up to 5 plan pages.
Essential
$99
One legend-based scope and up to 10 plan pages.
Professional
$179
One legend-based scope and up to 25 plan pages.
Multi-Scope
$299
Fixture/device counts plus cable/conduit runs, up to 25 plan pages.
Large Set
$499
One or both legend-based outputs, up to 250 plan pages.
Credit packs and monthly plans are available after login. No unlimited tier, no per-seat license, and no charge before confirmation.
See complete pricingCommon questions
What estimators usually ask first.
Turn your next readable legend into source-linked quantities.
Start with one sheet free, then use credits only when the verified scope makes sense.
Check my plans free
